Chapter 9: Object Counting by Binary Conversion

Checks the number of objects (max. 3000 items.) when there is more than one
object in an image. Measurement of the object's position is optional.
Purpose
- When the specified pixel field has been converted to a binary image, the white
areas are measured or identified as separate objects and counted.
Applications
Counting the number of food products or parts.
Objects
Examples
- Inspection sequence
Capture an image
Object Counting by Binary Conversion
[Measurement result]
- Number of objects/total area
Convert it to a Measure the number of
binary image objects/total area
9-1
9
