CDM-570/570L Satellite Modem with Optional IP Module
Ethernet Management (Base Modem)
14.4

SNMP Interface

The Simple Network Management Protocol (SNMP) is an application-layer protocol
designed to facilitate the exchange of management information between network devices.
The CDM-570/570L SNMP agent supports both SNMPv1 and v2c.
For proper SNMP operation, the CDM-570/570L MIB files must be used with the
associated version of the CDM-570/570L base modem M&C. Please refer to the
CDM-570/570L SW Release Notes for information on the required FW/SW
IMPORTANT
compatibility.
14.4.1

Management Information Base (MIB) Files

MIB files are used for SNMP remote management and consist of Object Identifiers
(OID's). Each OID is a node that provides remote management of a particular function. A
MIB file is a tree of nodes that is unique to a particular device.
There are five MIB files associated with the CDM-570:
There are five MIB files associated with the CDM-570L:
MIB File/Name
fw10874-2-.mib
ComtechEFData
MIB file
fw10874-4c .mib
CDM-570/570L
MIB file
fw10874-5a .mib
CDM-570/570L
Traps MIB file
Fw/10874-6a.mib
CDM-570L
BUC/LNB MIB
file
Fw/10874-7-.mib
CDM-570L
BUC/LNB
Traps M2B file
Fw/10874-8-.mib
CSAT-5060
MIB file
Fw/10874-8-.mib
KST-2000A/B
MIB file
Description
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data
products and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full
path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFD
ata(6247)
Module: ComtechEFData
MIB file consists of all of the OID's for management of the modem functions
Trap MIB file is provided for SNMPv1 traps common for base modems.
Provided for management of the CDM-570L BUC and LNB.
Trap MIB file is provided for SNMPv1 traps unique to CDM-570L.
MIB file consists of all the OIDs for management of the CSAT-5060
Transceiver connected to the CDM-570 modem through FSK.
MIB file consists of all the OIDs for management of the KST-2000A/B
Transceiver connected to the CDM-570 modem through FSK.
