CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
If BUC is selected, the following menu is displayed:
BUC:DC=47.8V,3.25A SW=05
T=+38C PLL=Flt Pwr=02.1W
The menu displays the following parameters:
(DC Power) If a BUC supply is installed, displays
measured BUC supply voltage and load current, measured
DC
at the Tx-IF connector.
(Temperature) If BUC FSK is enabled, displays BUC
T
ambient temperature in °C.
If BUC FSK is enabled, displays the M&C software
SW
version of the BUC.
If BUC FSK is enabled, displays the fault status of the
PLL
BUC PLL synthesizers.
(Output) If BUC FSK is enabled, displays the output power
Pwr
as measured by the BUC power monitor.
Press ENTER or CLEAR to return to the next-highest menu.
6–49
Revision 4
MN/CDM570L.IOM
