Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
TX Payload TPE= 1 byte, value
Compression of 0, 1, 2 or 3
enable/disable
3xDES DEK[1..8]= 48 bytes,
Encrypt Key numerical
3xDES DDK[1..8]= 48 bytes,
Decrypt Key numerical
SMTP Server SIA= 15 bytes,
IP Address numerical
Page 14 of 54
Description of Arguments
to Query
Command or Query where,
0=Disabled
1= Enabled (EasyConnect Only mode)
2 = PerRoute (read-only when FAST feature is purchased in
router mode)
3 = Unavailable (read-only when FAST feature not purchased)
Acts as command, only in EasyConnect mode. In router mode, it's
read-only.
Enables or disables the Transmit 3xDES feature.
Restriction: Can not enable if the 3xDES FAST feature has not
been purchased
Command or Query.
3xDES encrypt key [192-Bit], where:
Example: DEK[1]=
222222222222222244444444444444446666666666666
666
All are Hexadecimal digits. [0...F], a total of 48 Hex digits.
Command or Query.
3xDES decrypt key, where:
Example: DDK:0=
222222222222222244444444444444446666666666666
666
All are Hexadecimal digits. [0...F], a total of 48 Hex digits.
Command or Query.
Used to set the IP address of the SMTP server where mail should
be sent, in the format:
xxx.xxx.xxx.xxx is the IP address
Example: <1/SIA=010.006.030.001. When not configured, it
returns >0001/SIA=0.0.0.0
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
TPE = TPE? TPE =x
TPE! (see description of
arguments)
DEK = DEK[1..8]? DEK= x [1..48]
DEK! (see description of
arguments)
DDK = DDK[1..8]? DDK =x [1..48]
DDK! (see description of
arguments)
SIA = SIA? SIA = xx.xxx.xxx.xxx
SIA! (see description of
arguments)
