3.4.1 IP Commands

3.4.1.1 Admin Commands
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
System SWM= 1 byte, value
Working Mode of 0 through 1
EasyConnect EMO= 1 byte, value
Multicast of 0 or 1
Option
Header HRR= 3 bytes
Compression
Refresh rate –
UDP/RTP1
Page 15 of 54 13
Description of Arguments
to Query
Command or Query here:
1 -- Router - Small Network
2 -- Router - Large Network
3 -- Router - Point to Point
4 -- Router - Vipersat
5 -- Easy Connect.
Router-Vipersat mode needs the vipersat option to be available on
the modem. Changing the address/working mode may reboot the
modem.
Command or Query where,
0=Disabled
1= Enabled
Enables or disabled forwarding of multicast traffic while in
EasyConnect mode.
Valid only when in EasyConnect mode on 570.
Command or Query.
Header compression refresh rate, 1 to 600
Resolution=1 packet
Refresh rate for UDP/RTP1 streams.
Example: HRR=50
Restrictions: 570 only
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
SWM= SWM? SWM =x
SWM! (see description of
arguments)
EMO = EMO? EMO =x
EMO! (see description of
arguments)
HRR = HRR? HRR =xxx
HRR! (see description of
arguments)
MN/CDM570L.AA4
