3.4.8 Routing Commands

Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Route Table RTE RTE[1..256]=
variable
Page 15 of 54 35
Description of Arguments
to Query
Command or Query.
sssssssssssss|ddd.ddd.ddd.ddd/DD|i|nnn.nnn.nnn.nnn|hhhh|t|p|c|k|S
s = Route Name up to 13 characters. It should be unique. Reusing
of route names with different index, will endup modifying the
existing route.
d = Destination IP Address in xxx.xxx.xxx.xxx/yy where
xxx.xxx.xxx.xxx is IP address and
yy – Subnet mask bits. To mean 'Any IP Address' indicate it by
***.***.***.***/** format.
D = Destination Subnet Mask Bits.
i = Interface 1 – Sat and 0 – Ethernet
n = Next Hop IP Address in xxx.xxx.xxx.xxx format.
To be valid the next hop should be on the same subnet
as the router IP Address. This field will be all '*' for a 'SAT'
directed route. It means, for a route with valid HDLC address this
field will be '***************'.
h = HDLC Addr in 4-digit hexadecimal number. Valid
range is 0x00 to 0xFE in Router-Small Network mode.
And 0x0000 to 0x7FFE for Router-Large Network
mode. This field will be all '*' for 'ETH' directed route.
It means, if the route has a valid next-hop, then this field is '****'
[meaning HDLC Address is not Used.]. HDLC Address is not used
in point-to-point mode, may default to '1'.
t = Header Compression 0 – No 1 – Yes.
p = Payload Compression 0 – No 1 – Yes.
c = DES Encryption 0 – No 1 – Yes.
k = DES Key to use 0 – Don't use any key 1 – 8 use as
mentioned and 9 – Use Random key.
S = Multicast state 0-None 1=Eth-to-Sat 2=Sat-to-Eth
3=toBoth
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
RTE = RTE[1..256]? RTE[1..256] = xxx (see
RTE! description of
arguments)
MN/CDM570L.AA4
