Comtech EF Data CDM-570L Installation And Operation Manual page 262

CDM-570/570L Satellite Modem with Optional IP Module
Serial Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
BUC Address BAD= 2 byte, value
of 01 to 15
BUC Comms BCE= 1 byte, value
enable of 0 or 1
BUC Power BPC= 1 byte, value
Control of 0 or 1
BUC 10 MHz BFR= 1 byte, value
Reference of 0 or 1
BUC Output BOE= 1 byte, value
Enable of 0 or 1
BUC High BCH= 4 bytes
Current Limit
BUC Low BCL= 4 bytes
Current Limit
Description of Arguments
to Query
Command or Query. CDM-570L Only
Indicates the BUC Address, in the form: xx, where xx is between
01 and 15.
Example: BAD=03
Command or Query. CDM-570L Only
Enables or disables communications, via the FSK link, with an
externally connected Block Up Converter (BUC), where:
0=Disabled
1=Enabled
Example: BCE=0 (Disabled)
Command or Query. CDM-570L Only
0=Disable BUC DC Power
1=Enable BUC DC Power
Example: BPC=0 (BUC DC power disabled)
Command or Query. CDM-570L Only
Enables or disables the 10 MHz frequency reference to the BUC
0 = Disabled
1 = Enabled
Example: BFR=0 (BUC 10MHz reference disabled)
Command or Query. CDM-570L Only
Indicates BUC Output enable,
0 = Off (output disabled)
1 = On (output enabled)
Example: BOE=1 (BUC output is enabled)
Command or Query. CDM-570L Only
BUC High Current Limit, a value between 500 and 4000 mA
Example: BCH=3100
Command or Query. CDM-570L Only
BUC Low Current Limit, a value between 0 and 3000 mA
Example: BCL=0600
Response to
Command
BAD =
BAD?
BAD *
BAD #
BCE=
BCE?
BCE*
BCE#
BPC=
BPC?
BPC*
BPC#
BFR=
BFR?
BFR*
BFR#
BOE=
BOE?
BOE*
BOE#
BCH=
BCH?
BCH*
BCH#
BCL=
BCL?
BCL*
BCL#
13–28
Revision 4
MN/CDM570L.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
BAD? BAD=xx
(see description of
arguments)
BCE? BCE=x
(see description of
arguments)
BPC? BPC=x
(see description of
arguments)
BFR? BFR=x
(see description of
arguments)
BOE? BOE=x
(see description of
arguments)
BCH? BCH=xxxx
(see description of
arguments)
BCL? BCL=xxxx
(see description of
arguments)
