CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
VERY IMPORTANT NOTE:
The FEC type takes the highest configuration priority, and the selection here depends on
what, if any, optional plug-in codecs are installed. The choice of FEC type then
IMPORTANT
determines what demodulation types, code rates, and data rates are available. The order
of hierarchy is therefore:
FEC type ► Demodulation type ► Code Rate ► Data Rate
(Highest)
If the user changes a parameter within this hierarchy, the other parameters may become
invalid. In this case, the software will change those other parameters, in order that the
configuration remains valid at all times.
Example: Suppose the user has selected Viterbi + Reed-Solomon, QPSK, Rate 1/2.
Now, the user changes the demodulation type from QPSK to 16-QAM. In this case, Rate
1/2 is no longer a valid code rate, and so it will be automatically changed to the nearest
valid code rate (Rate 3/4).
Each of the configuration sub-branches will now be described in detail.
6.8.1

(CONFIG, RX) FEC TYPE

Rx FEC: Viterbi Vit+RS
TCM+RS TPC LDPC Uncoded
IMPORTANT NOTE: All possible choices are presented at all times. If an option is
not installed (either Hardware, or FAST) or valid, the ◄ ► arrow keys will force the
cursor to skip past the unavailable choice.
IMPORTANT
Viterbi
Vit+RS (Viterbi
+Concatenated Reed-
Solomon)
TCM+RS (Trellis Coded
Modulation + Concatenated
Reed-Solomon)
TPC (Turbo Product Codec)
LDPC (Low Density Parity
Check Codec) WHEN
AVAILABLE -consult
factory
Uncoded
CASE
Always valid
If the RS codec is installed
If the RS codec is installed
AND 8-PSK FAST is enabled
If the TPC codec is installed
If the TPC/LDPC codec is
installed
Always valid - BPSK, QPSK
and OQPSK only.
6–21
(Lowest)
RULES
Fixed at 8-PSK and
Rate 2/3
Forces Code Rate to
1:1 (uncoded)
Revision 4
MN/CDM570L.IOM
COMMENT
