CDM-570/570L Satellite Modem with Optional IP Module
Appendix F
F.3.3.37 (ODU,ENABLE,1:1,CSAT#1,INFO)
(ODU,ENABLE,1:1,CSAT#2,INFO)
(ODU,ENABLE,STAND-ALONE,INFO)
Rx: ON
This window provides the CSAT Receiver information including receiving status,
Rx Frequency, Rx Attenuation, Rx Mute state and Rx Slope adjustment. Press ENT.
F.3.3.38 (ODU,ENABLE,1:1,CSAT#1,INFO)
(ODU,ENABLE,1:1,CSAT#2,INFO)
(ODU,ENABLE,STAND-ALONE,INFO)
LNA: On
Fault Logic: No-Summary
This window provides the current state of the LNA functions. Press ENT.
F.3.3.39 (ODU,ENABLE,1:1,CSAT#1,INFO)
(ODU,ENABLE,1:1,CSAT#2,INFO)
(ODU,ENABLE,STAND-ALONE,INFO)
Cold Start: Off
Auto Fault Recovery: On
This window provides the current state of the Cold Start and Auto Fault Recovery
functions. Press ENT.
F.3.3.40 (ODU,ENABLE,1:1,CSAT#1)
(ODU,ENABLE,1:1,CSAT#2)
(ODU,ENABLE,STAND-ALONE)
ODU MONITOR: Tx Rx Misc
Pwr-Supp1 Pwr-Supp2 (◄ ►)
The operator uses this menu item to select enter 1 of 5 'Monitor Windows'. Use the
◄ ► arrow keys, then press ENT.
3625.0MHz 10.00dB
Unmuted Sl:0.0
Window: 99%
F–14
RECEIVER
RECEIVER
RECEIVER
LNA
LNA
LNA
MISC
MISC
MISC
MONITOR
MONITOR
MONITOR
Revision 4
MN/CDM570L.IOM
