CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
If Upper is selected, the following sub-menu is displayed:
BUC Current Alarm Upper
Limit:1200mA (◄ ►,▲ ▼,ENT)
Edit BUC Current Alarm Upper limit. This is accomplished by selecting
the digit to be edited, using the
then changed using the
ENTER. The range of current is 500 to 4000 mA.
If Lower is selected, the following sub-menu is displayed:
BUC Current Alarm Lower
Limit:1200mA (◄ ►,▲ ▼,ENT)
Edit BUC Current Alarm Lower limit. This is accomplished by selecting
the digit to be edited, using
then changed using
ENTER. The range of current is 0 to 3000 mA.
(CONFIG, ODU, BUC) LO
If LO is selected, the following sub-menu is displayed:
BUC LO Frequency:
12000 MHz (◄ ►,▲ ▼,ENTER)
Edit the value of the BUC LO frequency. This is accomplished by selecting the
digit to be edited, using the
changed using the
▲ ▼
valid range is from 3000 to 65000 MHz.
Note this value is used to display the RF frequency of the modem/BUC
combination. If a value of 00000 is entered here (the default), then no RF
frequency will be displayed on the CONFIG, Tx, Tx Freq menu.
arrow keys. The value of the digit is
◄ ►
arrow keys. The user should then press
▲ ▼
arrow keys. The value of the digit is
◄ ►
arrow keys. The user should then press
▲ ▼
arrow keys. The value of the digit is then
◄ ►
arrow keys. The user should then press ENTER. The
