CDM-570/570L Satellite Modem with Optional IP Module
Appendix F
F.3.3.14 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER) MUTE
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER) MUTE
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER) MUTE
ODU Tx Mute State:
Muted
The user is prompted to select either Muted or Unmuted, using the
then to press ENT.
F.3.3.15 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER) SLOPE
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER) SLOPE
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER) SLOPE
ODU Tx Slope Mode:
Manual
The user is prompted to select either Manual or Calibrated, using the
then to press ENT.
F.3.3.16 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER,SLOPE)
MANUAL
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER,SLOPE)
MANUAL
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER,SLOPE)
MANUAL
ODU Tx Slope:
0.0
If Manual mode is selected, the user is prompted to edit the transmit slope setting. This
is accomplished using the
F.3.3.17 (ODU,ENABLE,1:1,CSAT#1,CONFIG)
(ODU,ENABLE,1:1,CSAT#2,CONFIG)
(ODU,ENABLE,STAND-ALONE,CONFIG) RECEIVER
ODU RX: Frequency Atten
Mute Slope
This menu item is used to select which ODU Receiver parameter is to be modified. Use
◄ ►
the
◄ ►
Unmuted ( ,ENT)
◄ ►
Calibrated (
▲ ▼,
( ENT)
▲ ▼ arrow keys. The user then presses ENT.
◄ ►
( ,ENT)
arrow keys, then press ENT.
)
RECEIVER
RECEIVER
F–7
Revision 4
MN/CDM570L.IOM
◄ ►
arrow keys,
◄ ► arrow keys,
