CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
17.2.8.3 Framing Mode Configuration
The Framing Mode Configuration page is activated from the Configuration page.
The Framing Mode Configuration page contains the following options/fields:
Menu Options/Fields
Framing Mode
EDMAC Mode
EDMAC Slave Address Range
AUPC
Max Power Reached Action
Remote Demod Unlock Action
Target Eb/No of Remote Demod
(db)
Maximum Power Limit
Entry Description
F 1 -- Unframed
2 -- EDMAC Framing
3 -- EDMAC-2 Framing
D 1 -- Unframed
2 -- EDMAC Framing
3 -- EDMAC-2 Framing
V 10 to 9990 in multiple of ten.
A 1 -- Enable
2 -- Disable
R 1 -- No_Action
2 -- Generate_TX_Alarm
U 1 -- Nominal_Power
2 -- Maximum_Power
E 0.0 to 9.9
M 0 to 9
17–50
