CDM-570/570L Satellite Modem with Optional IP Module
Appendix F
F.3.4.10 (ODU,ENABLE, CONFIG)
KST RX: Frequency
LNA
This menu item is used to select which ODU Receiver parameter is to be modified. Use
the ◄ ► keys, then press ENT.
F.3.4.11 (ODU,ENABLE, CONFIG,RECEIVER)
ODU Rx Frequency:
10950.0 MHz (
The user is prompted to edit the receive frequency. This is accomplished by selecting the
digit to be edited, using the ◄ ► keys. The value of the digit is then changed using the
▲ ▼ keys. The user may then press ENT.
F.3.4.12 (ODU,ENABLE, CONFIG,RECEIVER)
ODU Rx Attenuation:
15 dB
The user is prompted to edit the receive attenuation. This is accomplished by selecting
the digit to be edited, using the ◄ ► keys. The value of the digit is then changed using
the ▲ ▼ keys. The user then presses ENT.
F.3.4.13 (ODU,ENABLE, CONFIG,RECEIVER)
If the ODU is a KST-2000A unit, the following menu is displayed.
LNA:
Calibrate
If the ODU is a KST-2000B unit, a different menu is displayed.
LNB:
Calibrate Band
The user may select a parameter using the ◄ ► keys, then press ENT.
Atten
◄ ►,E
(
◄ ►,▲ ▼,
◄ ►,▲ ▼,
( ENT)
State Fault-Logic
◄ ►,
(
State Fault-Logic
◄ ►,
(
RECEIVER
NT)
ENT)
ENT)
ENT)
F–20
MN/CDM570L.IOM
FREQUENCY
ATTEN (Attenuation)
LNA / LNB
Revision 4
