CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
Menu Options/Fields
Receive 3XDES Decryption
Tx Header Compression
Rx Header Compression
Tx Payload Compression
Rx Payload Compression
Vipersat Feature Codes
Save Parameters
Exit
Entry
Read This feature must be purchased.
Only
Available allows the
received from the Satellite Interface.
When Unavailable the
packets received from the Satellite Interface. This option
is auto-sensed by a bit carried in packet headers. This
option is always available if the option is purchased.
H This option will compress headers. Headers available
for compression can be referenced in the IP Header
Compression section. Note that in easyConnect™ mode
all Ethernet Headers will be compressed whether or not
this feature is enabled. In Router mode, this screen will
show Available, and the option must be enabled per
route in Route table.
K This option tells the system to expect received streams
to be Header compressed. Note a CDM-IP modem must
receive all streams compressed or not compressed. The
modem has no way to distinguish between compressed
or not compressed.
C This option allows a stream of traffic to be payload
compressed. Payload is considered everything inside
the HDLC satellite frame. Therefore, IP headers could
be compressed as well. Note that in easyConnect™
mode, the option is enabled/disabled for all traffic. In
Router mode, Payload compression will show Available,
and one must set the option Per Route in Routing table.
Read Receive payload compression option allows a unit
Only receiving a stream of data that has been payload
compressed to be correctly uncompressed. This option
is auto-sensed by a bit carried in packet headers. This
option is always available if the option is purchased.
F This option allows a user to enter a Vipersat features
enable code that has been provided by Comtech
Vipersat for modem configured to operate under VMS
control.
S This option allows a user to save the current
configuration to permanent storage. This configuration
will be restored on each successive power cycle.
X This option allows a user to exit the current menu and
return to its parent menu.
17–12
MN/CDM570L.IOM
Description
IP M
odule to decrypt packets being
IP M
odule cannot decrypt
Revision 4
