CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
17.2.3.1 QoS Configuration Page – Max/Priority Mode
The QoS Rules Configuration page is activated from the QoS Configuration page.
The QoS Rules Configuration page contains the following options/fields when in Max/Pri
Mode:
Menu Options/Fields
Rule 01 – 08 (32)
(The 8 currently displayed
QoS Rules, up to 32 can be
defined).
By selecting a QoS Rule,
the user will be asked to
define the following:
Entry
1 - 08
17–26
Description
Max/Pri QoS can be assigned to up to
32 different types of flows to be defined
by the user. Flows can be defined by
any combination of Protocol (FTP, UDP,
RTP, etc.), Source/Destination IP
(specific or range), and/or Layer 3
Source/Destination Port.
