CDM-570/570L Satellite Modem with Optional IP Module
Preface

EMC (Electromagnetic Compatibility)

In accordance with European Directive 89/336/EEC, the CDM-570/570L Modem has
been shown, by independent testing, to comply with the following standards:
Emissions:
Immunity:
Additionally, the CDM-570/570L has been shown to comply with the following
IMPORTANT
•
•
•
EN 55022 Class B - Limits and methods of measurement of radio
interference characteristics of Information Technology Equipment.
(Also tested to FCC Part 15 Class B)
EN 50082 Part 1 - Generic immunity standard, Part 1: Domestic,
commercial and light industrial environment.
standards:
EN 61000-3-2
EN 61000-3-3
EN 61000-4-2
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-8
EN 61000-4-9
EN 61000-4-11
EN 61000-4-13
In order that the Modem continues to comply with these standards,
observe the following instructions:
Connections to the transmit and receive IF ports ('N' type female connectors)
should be made using a good quality coaxial cable - for example, RG213/U.
All 'D' type connectors attached to the rear panel must have back-shells that
provide continuous metallic shielding. Cable with a continuous outer shield
(either foil or braid, or both) must be used, and the shield must be bonded to the
back-shell.
The equipment must be operated with its cover on at all times. If it becomes
necessary to remove the cover, the user should ensure that the cover is correctly
re-fitted before normal operation commences.
Harmonic Currents Emission
Voltage Fluctuations and Flicker
ESD Immunity
EFT Burst Immunity
Surge Immunity
RF Conducted Immunity
Power frequency Magnetic Field Immunity
Pulse Magnetic Field Immunity
Voltage Dips, Interruptions, and Variations Immunity
Immunity to Harmonics
xix
Revision 4
MN/CDM570L.IOM
