Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
SNMP Trap STB= 15 bytes,
Destination IP Numerical
Address-2
SNMP Trap STV= 1 byte, value
Version of 0 or 1
SNMP Trap SAT= 1 byte, value
Enable of 1 or 2
Authentication
Traps
SNMP SSC= 128 bytes,
System characters,
Contact
SNMP SSN= 128 bytes,
System Name characters,
SNMP SSL= 128 bytes,
System characters,
Location
Page 14 of 54
Description of Arguments
to Query
Command or Query.
Used to set the IP address of the SNMP Trap destination IP
Address where traps will be sent, in the format:
xxx.xxx.xxx.xxx is the IP addresss
Example: 010.006.030.001
Returns >0001/STB=0.0.0.0 When not configured.
Command or Query.
1=Snmpv1
2=Snmpv2
Specifies the version of snmp traps that should be sent.
Command or Query
where,
2=Disabled
1= Enabled
Enables or disables sending SNMP authentication traps.
Command or Query.
SNMP System Contact string
Example: <1/SSC=Joe Net Admin. If not configured it returns
empty string.
<1/SSC=
Command or Query.
SNMP System Name string
Example: <1/SSN=Remote1. If not configured it returns empty
string.
<1/SSC=
Command or Query.
SNMP System Location string
Example: <1/SSL=Upstairs back right. If not configured it returns
empty string.
<1/SSL=
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
STB = STB? STB = xx.xxx.xxx.xxx
STB! (see description of
arguments)
STV = STV? STV = x
STV! (see description of
arguments)
SAT = SAT? SAT =x
SAT! (see description of
arguments)
SSC = STC? STC =x [1..128]
SSC! (see description of
arguments)
SSN = SSN? SSN =x [1..128]
SSN! (see description of
arguments)
SSL = SSL? SSL =x [1..128]
SSL! (see description of
arguments)
