Comtech EF Data CDM-570L Installation And Operation Manual page 429

CDM-570/570L Satellite Modem with Optional IP Module
Appendix F
F.3.3.8 (ODU,ENABLE,1:1,CSAT#1)
(ODU,ENABLE,1:1,CSAT#2)
(ODU,ENABLE,STAND-ALONE)
ODU SELECT: Config
Monitor
The user is prompted from 1 of 4 sub-menu branches using the
press ENT.
F.3.3.9 (ODU,ENABLE,1:1,CSAT#1)
(ODU,ENABLE,1:1,CSAT#2)
(ODU,ENABLE,STAND-ALONE)
ODU CONFIG: Transmitter
Receiver
The user uses this menu item to select either the 'Transmitter configuration branch",
"Receiver configuration branch" or "Miscellaneous configuration branch". Use the
arrow keys, then press ENT.
F.3.3.10 (ODU,ENABLE,1:1,CSAT#1,CONFIG)
(ODU,ENABLE,1:1,CSAT#2,CONFIG)
(ODU,ENABLE,STAND-ALONE,CONFIG)
ODU TX: Frequency Atten
Amplifier Mute Slope
This menu item is used to select which ODU Transmitter parameter is to be modified.
Use the
◄ ►
Alarms (
◄ ►
Misc (
◄ ►
arrow keys, then press ENT.
Selections
Selections
Selections
Info
,ENT)
CONFIG (Configuration)
CONFIG (Configuration)
CONFIG (Configuration)
,ENT)
◄ ►
F–5
Revision 4
MN/CDM570L.IOM
◄ ► arrow keys, then
◄ ►
TRANSMITTER
TRANSMITTER
TRANSMITTER
