Comtech EF Data CDM-570L Installation And Operation Manual page 259

CDM-570/570L Satellite Modem with Optional IP Module
Serial Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Temperature N/A 3 bytes
Equipment ID N/A 11 bytes
Description of Arguments
to Query
Query only.
Unit returns the value of the internal temperature, in the form of
sxx (degrees C).
s = sign (+ or - character)
xx = value
Example: TMP=+26
Query only.
Unit returns information concerning the equipment identification,
and the option field, in the form abbbcdefghi;
where:
a = Turbo option: 0 = None, 1 = Turbo, 2 = TPC/LDPC
bbb = defines the modem model number
CDM-570 = 570
CDM-570L = 571
c = RS Codec Option: 0 = None, 1 = Installed
d = Data Rate Option: 0 = Base (512 kbps), 1 = up to 2048 kbps,
2 = up to 5000 kbps, 3 = up to 9980 kbps
e = Higher-order modulation: 0= None, 1 = 8-PSK/8-QAM,
2 = 16QAM, 3 = 8-PSK/8-QAM and 16QAM
f = IP Module: 0 = None, 1 = Installed
g = BUC option: 0 = None, 1 = 100 Watt, 2 = 150 Watt
h = Spare – for future use
i = Spare – for future use
Example: EID=157101311xx means Turbo, CDM-570L, No RS
codec, up to 2048bps, 8-PSK/8-QAM and 16-QAM, IP Module
installed, 100 Watt BUC supply installed
Response to
Command
N/A
N/A
13–25
Revision 4
MN/CDM570L.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
TMP? TMP=sxx
(see description of
arguments)
EID? EID= abbbcdefghi
(see description of
arguments)
570 is the CDM-570
571 is the CDM-570L
