CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
(CONFIG, REMOTE, ETHERNET, SNMP) Traps
If Traps is selected, the following sub-menu is displayed:
Traps: Community Version
IP Addr#1 IP Addr#2
If Community is selected, the following sub-menu is displayed.
Trap Community: (◄ ►,▲ ▼)
comtech
Edit the SNMP Read or Write Community string using the
◄ ►
and
▲ ▼
bottom line are available. The cursor selects the position on the
◄ ►)
bottom line (
printable ASCII characters are available with the exception of
the backslash (ASCII code 92) and ~ (ASCII code 126). When
the user has composed the string, press ENTER. All trailing
spaces are removed from the Community string upon entering.
If Version is selected, the following sub-menu is displayed.
Trap Version:
SNMPv1
Select SNMPv1 or SNMPv2 using the
ENTER.
If IP Addr#1 is selected, the following sub-menu is displayed.
Trap IP #1:
000.000.000.000
If IP Addr#2 is selected, the following sub-menu is displayed.
Trap IP #2:
000.000.000.000
These two IP Addresses are Trap Destination's IP Addresses.
Edit the IP Address by using the
◄ ► and
▲ ▼
000.000.000.000, it means Trap is disabled.
6–10
(◄ ►)
arrow keys. Only the first 20 characters on the
and the character is then edited (
(◄ ►,ENT)
SNMPv2
(◄ ►,▲ ▼)
(◄ ►,▲ ▼)
arrow keys. If both Trap IP Address are
Revision 4
MN/CDM570L.IOM
. All
▲ ▼)
◄ ►
then, press
