Comtech EF Data CDM-570L Installation And Operation Manual page 21

Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Trasnmit DES TDE= 1 byte, value
enable/disable of 0, 1, 2 or 3
TX Header THE= 1 byte, value
Compression of 0, 1, 2 or 3
enable/disable
RX Header RHE= 1 byte, value
Compression of 0, 1, 2 or 3
enable/disable
Page 15 of 54 17
Description of Arguments
to Query
Command or Query where,
0=Disabled
1= Enabled (EasyConnect Only mode)
2= PerRoute (read-only when FAST feature is purchased in router
mode)
3 = Unavailable (read-only when FAST feature not purchased)
Acts as command, only in EasyConnect mode. In router mode, it's
read-only.
Enables or disables the Transmit 3xDES feature.
Restriction: Can not enable if the 3xDES FAST feature has not
been purchased
Command or Query where,
0=Disabled
1= Enabled (EasyConnect Only mode)
2 = PerRoute (read-only when FAST feature is purchased in router
mode)
3 = Unavailable (read-only when FAST feature not purchased)
Acts as command, only in EasyConnect mode. In router mode, it's
read-only.
Enables or disables the Transmit 3xDES feature.
Restriction: Can not enable if the 3xDES FAST feature has not
been purchased
Command or Query where,
0=Disabled
1= Enabled
Enables or disables the Transmit 3xDES feature.
Restriction: Can not enable if the 3xDES FAST feature has not
been purchased
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
TDE = TDE? TDE =x
TDE! (see description of
arguments)
THE = THE? THE =x
THE! (see description of
arguments)
RHE = RHE? RHE =x
RHE! (see description of
arguments)
MN/CDM570L.AA4
