Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Route Table
(Continued)
Page 14 of 54
Description of Arguments
to Query
When called using an existing index, the command is treated as a
"modify". Only new routes can be added at the END of the list:
Example:
RTN?
RTN=3
<1/rte[3]=
rt3|239.111.102.222.32|0|192.168.001.022|00AB|0|0|1|5|3
Sat Directed Route:
>0001/RTE[1]=rt1|011.012.013.014/32|1|***.***.***.***|1111|0|0|
0|0|0
Eth Directed Route:
>0001/RTE[4]=rt4|012.013.014.015/32|0|192.168.001.111|****|0|0|
0|0|0
Note: To be able to set/get the route entries, the system should be in
the routing. It may retur RTE!, if system is in EasyConnect mode.
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
MN/CDM570L.AA4
