Comtech EF Data CDM-570L Installation And Operation Manual page 264

CDM-570/570L Satellite Modem with Optional IP Module
Serial Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
BUC Software N/A 2 bytes
Version
BUC Current N/A 4 bytes
BUC Voltage N/A 4 bytes
Terminal Tx N/A 10 bytes
Frequency
Terminal Rx N/A 10 bytes
Frequency
Description of Arguments
to Query
Query only. CDM-570L Only
Indicates the BUC software version, in the form xx,
Example: BSV=05 (Software version 05)
If not available, response is 00
Note: This command is only valid when the FSK and BUC power
are turned On.
Query only. CDM-570L Only
Indicates the value of the BUC Current, in the form: xxxx, where
xxxx is between 0 and 9999, units mA.
If not available, response is 0000.
Example: BDC=3100
Query only. CDM-570L Only
Indicates the value of the BUC Voltage, in the form: xx.x, where
xx.x is between 0 and 64.0
If not available, response is 00.0.
Example: BDV=43.6 (BUC DC voltage is 43.6 volts)
Query only. CDM-570L Only
Terminal Tx Frequency, where frequency = BUC LO ± TFQ
Resolution=100 Hz
Returns 00000.0000 if LNB LO is zero
Example: TTF=14250.9872
Query only. CDM-570L Only
Terminal Rx Frequency, where frequency = LNB LO ± RFQ
Resolution=100 Hz
Returns 00000.0000 if LNB LO is zero
Example: TRF=11650.2249
Response to
Command
N/A
N/A
N/A
N/A
N/A
13–30
Revision 4
MN/CDM570L.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
BSV? BSV=xx
(see description of
arguments)
BDC? BDC=xxxx
(see description of
arguments)
BDV? BDV=xx.x
(see description of
arguments)
TTF? TTF=xxxxx.xxxx
(see description of
arguments)
TRF? TRF=xxxxx.xxxx
(see description of
arguments)
