CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
(CONFIG, TX, PWR, MODE) AUPC
Target-Eb/No
Alarm DemodUnlock (◄ ►)
Select either Target EbNo, Max-Range, Alarm or Demod-Unlock using the
► arrow keys. The user should then press ENTER.
(CONFIG, TX, PWR, MODE, AUPC) TARGET EbNo
Remote Demod - Target
Min Eb/No:9.9dB (◄ ►,▲ ▼)
Edit the target Eb/No of the remote demod, using the
keys. Default value is 3.0 dB, and upper limit is 9.9 dB. The user should then
press ENTER.
(CONFIG, TX, PWR, MODE, AUPC) MAX RANGE
Maximum-permitted Power
increase: 1dB
Edit the maximum permitted increase in power level (when in AUPC mode),
using the ▲ ▼ arrow keys. Default value is 1dB, and upper limit is 9 dB. Then
press ENTER.
(CONFIG, TX, PWR, MODE, AUPC) ALARM
Action when max Tx Power
reached: None TxAlarm ◄ ►
Select the action that will occur if the AUPC causes the maximum output power
level to be reached, either None or TxAlarm. Then press ENTER.
(CONFIG, TX, PWR, MODE, AUPC) DEMOD-UNLOCK
Action when Remote Demod
unlocks: Nom-Pwr Max-Pwr
Select the action that will occur if the remote demod is unlocked. The choices
are: Nom-Pwr (Nominal Power), where the output level will revert to the
nominal power level set under Manual, or Max-Pwr, (Maximum Power), where
the output level will change to the maximum permitted. The user should then
press ENTER.
Max-Range
(▲ ▼,ENT)
6–17
Revision 4
MN/CDM570L.IOM
◄ ► and
arrow
▲ ▼
◄
