3.4.4 Protocol Commands

Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
DHCP Relay DRA= 15 bytes,
IP Address numerical
Static Arp ARP= 256 bytes
table characters
Number of None 4 bytes,
ARP entries numerical
Page 15 of 54 27
Description of Arguments
to Query
Command or Query.
Used to set the IP address of the DHCP Server, in the format:
xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the IP address
Example: <1/DRA=010.006.030.001
Returns >0001/DRA=0.0.0.0 when not configured.
Command or Query.
ARP Entry in format xxx.xxx.xxx.xxx|mm:mm:mm:mm:mm:mm
Where xxx.xxx.xxx.xxx = IP address.
mm:mm:mm:mm:mm:mm. = MAC Address.
Duplicate IP addresses are not allowed. They must also be locally
attached (on the same subnet as the Ethernet interface). Using a
different index with existing IP address may modify the existing
ARP entry, rather than creating new one.
Example:
<1/arp[1]=010.020.030.040|00:11:ab:33:44:66
Returns >0001/ARP! When there is no ARP entry.
Query Only.
Returns the number of static arp entries.
Note: This command should be issued whenever a new ARP Entry
is added/deleted.
Query
Response to (Instruction
Command Code and
Qualifier)
DRA = DRA?
DRA!
ARP = ARP[1..256]?
ARP!
ARN = ARN?
ARN!
MN/CDM570L.AA4
Response to Query
DRA = xxx.xxx.xxx.xxx
(see description of
arguments)
ARP=x [1..256]
(see description of
arguments)
ARN=nnnn
(see description of
arguments)
