Comtech EF Data Documentation Update
Subject:
Date:
Document:
Part Number:
Collating Instructions:
Comments:
Changed TR A and TR B to DM A and DM B as shown:
Change Specifics:
Generic Signal
Pin #
Description
2 Transmit Data A
14 Transmit Data B
24 Transmit Clock A
11 Transmit Clock B
15 Internal Tx Clock A
12 Internal Tx Clock B
3 Receive Data A
16 Receive Data B
17 Receive Clock A
9 Receive Clock B
8 Receiver Ready A
10 Receiver Ready B
5 Clear to Send A *
13 Clear to Send B *
4 Request to Send A *
19 Request to Send B *
6 Data Set Ready A *
22 Data Set Ready B *
7 Signal Ground
1 Shield
Filename: T_ERRATA
Errata K
Revised Table 5-2 Data Interface Connector Pin Assignments
October 26, 2006
CDM-570/570L Satellite Modem with Optional IP Module,
Installation and Operation Manual, Rev. 4, dated April 12, 2006
MN/CDM-570L.EK4
Attach this page to page 5-2
Table 0-1. Data Interface Connector Pin Assignments
Direction
DTE to Modem
DTE to Modem
DTE to Modem
DTE to Modem
Modem to DTE
Modem to DTE
Modem to DTE
Modem to DTE
Modem to DTE
Modem to DTE
Modem to DTE
Modem to DTE
Modem to DTE
Modem to DTE
DTE to Modem
DTE to Modem
Modem to DTE
Modem to DTE
-
-
EIA-422
V.35
EIA-530
SD A SD A
SD B SD B
TT A SCTE A
TT B SCTE B
ST A SCT A
ST B SCT B
RD A RD A
RD B RD B
RT A SCR A
RT B SCR B
RR A RLSD
RR B -
CS A CTS
CS B -
RS A RTS
RS B -
DM A DSR
DM B -
SG SG
Shield FG
1
EIA-232 Circuit #
BA 103
- 103
DA 113
- 113
DB 114
- 114
BB 104
- 104
DD 115
- 115
CF 109
- 109
CB 106
- 106
CA 105
- 105
CC 107
- 107
AB 102
AN 101
