CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
6.14.5

(MONIT) AUPC

If the user selects AUPC, and the modem is not in Framed mode, the following sub-
menu is displayed:
Framing is required for
AUPC Monitor (ENT or CLR)
If the user selects AUPC, and the modem is in Framed mode, the following sub-menu is
displayed:
AUPC:Remote EbNo =14.0dB
TX Power Increase =2.2dB
The top line displays the value of Eb/No of the demodulator at the distant end of the
satellite link. The Eb/No will display Unlock if the remote demod is unlocked. The
bottom line shows how much the AUPC system has increased the output power. If AUPC
is not enabled, the value of Tx Power Increase will show as 0.0 dB.
6.14.6

(MONIT) ODU

If ODU is selected, the following sub-menu is displayed:
Outdoor Unit Monitor:
BUC
Select LNB or BUC, using the
If LNB is selected, the following menu is displayed:
◄ ►
,
LNB (
LNB Voltage: 13.1 volts
LNB Current: 235 mA(ENT)
The menu displays the LNB Voltage and Current. Press ENTER or CLEAR to
return to the next-highest menu.
ENTER)
◄ ► arrow keys, then press ENTER.
6–48
Revision 4
MN/CDM570L.IOM
