CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
Menu Options/Fields
Dropped - Filtered Multicast
Dropped – Multicast Disable
Group
Dropped – EasyConnect
Multicast Option
Dropped – Router Queue
Full
Reset Packet Counters
(Clears WAN, Ether, IP
stats)
Save Parameters
Exit
Entry
Total Dropped Multicast Packets received from the
satellite due to no SAT→LAN or
Multicast packet was dropped because, although route
existed, IGMP is being used, and there is no client
requesting forwarding of this traffic or due to a IGMP
"leave group" message.
Total Dropped Multicast Packets received from the
satellite due to the 'easyConnect Multicast Option'
feature not being enabled in easyConnect Mode.
Indicates that the router task is dropping packets due
to being full. Represents a graceful drop process when
the processor performance is being overdriven.
Executing this menu option resets all WAN, Ethernet
and IP Routing statistics gathered to zero.
This option allows a user to save the current
S
configuration to permanent storage. This configuration
will be restored on each successive power cycle.
X This option allows a user to exit the current menu and
return to its parent menu.
17–64
MN/CDM570L.IOM
Description
Revision 4
