CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
(CONFIG, ODU, BUC, M&C-FSK) TX-ON/OFF
If Tx-On/Off is selected, the following sub-menu is displayed:
BUC RF Output:
On Off
Select On or Off , using the ◄ ► arrow keys, then press ENTER.
(CONFIG, ODU, BUC) DC-POWER
If DC-Power is selected, the following sub-menu is displayed:
BUC DC Power:
On Off
Select On or Off , using the ◄ ► arrow keys, then press ENTER.
(CONFIG, ODU, BUC) 10MHz
If 10MHz is selected, the following sub-menu is displayed:
BUC 10MHz Reference:
On Off
Select On or Off , using the ◄ ► arrow keys, then press ENTER.
(CONFIG, ODU, BUC) ALARM
If Alarm is selected, the following sub-menu is displayed:
Set BUC Current Alarm:
Upper Lower
Select Upper or Lower , using the ◄ ► arrow keys, then press ENTER.
(◄ ►,ENTER)
(◄ ►,ENTER)
(◄ ►,ENTER)
(◄ ►,ENTER)
6–37
Revision 4
MN/CDM570L.IOM
