Chapter 19. SNMP INTERFACE

19.1

SNMP Interface

The Simple Network Management Protocol (SNMP) is an application-layer protocol
designed to facilitate the exchange of management information between network devices.
The CDM-570/570L SNMP agent supports both SNMPv1 and v2c.
For proper SNMP operation, the CDM-570/570L MIB files must be used with the
associated version of the CDM-570/570L base modem M&C and the IP module SW.
Please refer to the CDM-570/570L SW Release Notes for information on the required
IMPORTANT
FW/SW compatibility.
19.2

CDM-570/570L Management Information Base (MIB) Files

MIB files are used for SNMP remote management and consist of Object Identifiers
(OIDs). Each OID is a node that provides remote management of a particular function. A
MIB file is a tree of nodes that is unique to a particular device. There are six MIB files
associated with the CDM-570/570L:
MIB File/Name
fw10874-2-.mib
ComtechEFData
MIB file
fw10874-3B.mib
IP ModuleMIB
file
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data
products and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path: iso(1).org(3).dod(6).internet(1).private
(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
IP Module MIB file consists of all of the OIDs for management of the IP
functions.
19–1
Description
