CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
6.18.8

(UTIL) FAST (FAST code options)

FAST is the way to enable new options in the modem. Obtain the FAST code for the new
option from Comtech EF Data.
FAST:Cnfg View (H/W 0.03)
MainBoard S/N: 123456789
The FAST menu allows the user to either Configure (enter) a new FAST code into the
unit or to enable Demo Mode, or to View which options are currently installed. Select
Cnfg or View using the ◄ ► arrow keys, then press ENTER.
In addition, the user is also presented with the Hardware Revision Number, and the Main
Board Serial Number. This Serial Number is a unique identifier for the FAST upgrade
process (and is different from the Chassis Serial Number) and is required to obtain a new
FAST code from the factory.
If the user selects Cnfg, then the following menu is displayed:
FAST Configuration:
Edit Code
If the user selects Edit Code, then the following menu is displayed:
Edit 20 digit FAST Code:
00000000000000000000 ENT
Enter the code carefully. Use the
each character. Use the
ENTER. The modem will respond with "Configured Successfully" if the
new FAST option has been accepted as shown below.
Configured Successfully
(ENTER or CLEAR)
If, on the other hand, the FAST code is rejected, the following menu will
be displayed:
FAST Code Rejected!
(ENTER or CLEAR)
Demo Mode
◄ ►
arrow keys to edit the character, then press
▲ ▼
6–63
MN/CDM570L.IOM
arrow keys to move the cursor to
Revision 4
