CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
Menu Options/Fields
Rx Code Rate
Rx Demodulation
Rx Spectrum Inversion
Rx Data Inversion
Rx Descrambling
Rx Acquisition Range
(Sweep Width)
Eb/No Alarm Point
Rx Buffer Size
Save Parameters
Exit
Entry Description
1 – 5/16
R
2 – 21/44
3 – 1/2
4 – 2/3
5 – 3/4
6 – 7/8
7 – 0.95
9 – 1/1
Sets receive demodulation type
M
1 -- BPSK
2 -- QPSK
3 -- OQPSK
4 – 8-PSK
5 -- 16-QAM
6 -- 8-QAM
1 - Normal
U
2 - Inverted
1 - Normal
I
2 – Inverted
1 - Off
B
2 – On-Default
3 – On-IESS-315
W Valid ranges are from 0 to 200 kHz
(1 to 32HKz if symbol rate < 625Ksymbol)
P Valid ranges are from 0.1 to 16.0
1 -- Disabled
F
2 -- +/-_1024_bits
3 -- +/-_2048_bits
4 -- +/-_4096_bits
5 -- +/-_8192_bits
6 -- +/-_16384_bits
7 -- +/-_32768_bits
S This option allows a user to save the current
configuration to permanent storage. This configuration
will be restored on each successive power cycle.
X This option allows a user to exit the current menu and
return to its parent menu.
