CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
17.2.9.2.3 Ethernet Statistics Page
The Ethernet Statistics page is activated from the Statistics Menu page The Ethernet
Statistics page displays the statistics for the number of IP packets received from and sent
to the Ethernet interface.
The Ethernet Statistics page contains the following options/fields
Menu Options/Fields
Tx Bytes
Tx Good Frames
Tx Maximum Collision
Count
Tx Late Collision Count
Entry
Read The Ethernet Statistics presents the total packets
Only
transmitted and received for the Ethernet Port of the
M
odule.
Number of bytes transmitted by this Ethernet interface.
Number of good frames transmitted by this Ethernet
interface.
Number of frames that are not transmitted because they
encountered configured max collisions.
Number of frames dropped due to a late collision on the
Ethernet.
17–66
MN/CDM570L.IOM
Description
Revision 4
