F.3.4.14 (ODU,ENABLE, CONFIG,RECEIVER,LNA)
ODU LNA State:
On
The user is prompted to select either ON or OFF, using the ◄ ► keys, then to press
ENT. This controls whether or not the ODU will provide LNA POWER via the Receive
RF Cable.
F.3.4.15 (ODU,ENABLE, CONFIG,RECEIVER,LNA)
LNA Fault Logic: Summary
No-Summary
The user is prompted to select either SUMMARY or NO SUMM, using the ◄ ► keys,
then to press ENT. This controls whether or not LNA fault will activate the SUMMARY
FAULT RELAY.
F.3.4.16 (ODU,ENABLE, CONFIG,RECEIVER,LNA)
Calibrate LNA Current?
Cal
The user is prompted to select either CAL or EXIT, using the ◄ ► keys, then to press
ENT. Calibration allows the system to determine nominal LNA power consumption.
This need only be performed at initial installation.
F.3.4.17 (ODU,ENABLE, CONFIG, RECEIVER, LNB)
LNB Rx Band:
A
The user is prompted to select either A, B, or C, using the ◄ ► keys to press ENT. This
menu is to set LNB Receive Frequency Band, and it's ONLY used for the KST-2000B.
F.3.4.18 (ODU,ENABLE, CONFIG)
KST MISC: AGC Ref-Adjust
This menu item is used to select miscellaneous ODU parameters for modification. Use
the ◄ ► keys, then press ENT.
◄ ►,
Off (
◄ ►,
(
◄ ►,
Exit (
◄ ►,
B C (
◄ ►,
(
ENT)
ENT)
ENT)
ENT)
MISCELLANEOUS
ENT)
