CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
17.2

Main Menu Page

Menu pages are followed by a table listing the Menu Options/Fields, required Entry, and
Descriptions.
The Main Menu page has the following options/fields:
Menu Options/Fields
Administration
Interface Configuration
QoS Configuration
Route Table
Protocol Configuration
Vipersat Configuration
Entry
A The Administration menu provides a basic set of
standard admin functions to the
connected via telnet, navigation to this menu will be
restricted to the admin user.
Allows the user to configure the Ethernet and Satellite
I
interfaces.
Q Allows the user to define QoS rules for up to 32
different types of flows.
R
Allows a user to define how the
packets that it receives on its Ethernet and Satellite
interfaces.
P The Protocol Settings option allows the user to
configure various protocols used by the
These protocols currently include ARP and IGMP.
V Only used when the CDM-570/570L is used in a
Vipersat system.
17–3
MN/CDM570L.IOM
Description
IP M
odule. When
IP M
odule will route
IP M
Revision 4
odule.
