Qos Stats - Comtech EF Data CDM-570L Installation And Operation Manual

3.4.9.4

QoS Stats

Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Quality of N/A String of QoS
Service Stats
Statistics Get
Quality of QSC=xx xx – qos rule
Service Stats xx = qos index for
Clear rule index which to clear
stats.
Clear All QoS QSA= QSA=x
Queue
Statistics 1 – Clear all
stats
Page 15 of 54 45
Description of Arguments
to Query
Query only.
Displays the QoS queue statistics of all active queues.
nnn|pp|aaaaaaaaaa|bbbbb|cccccccccc|dddddddddd|eeeeeeeeee|fffff|g
gggg|hhhhh|iiii
n – QoS Rule Number
p – Protocol number [Refer to QSR]
a – Sent Packets
b – Pkts per Second
c – Sent Bytes
d – Dropped Packets
e – Dropped Bytes
f – Current Transmit Rate [Kbps]
g – Average Transmit Rate [Kbps]
h – Maximum Transmit Rate [ Kbps]
I – Active Flow count associated with this QoS Queue.
>0001/QST=
0|19| 0| 0|
1| 0| 0| 0|
Command only.
Clears the QoS statistics for a specified queue. The command can
be issued only on active/configured queue. To clear default queue
stats use '0'.
<1/QSC=0 will clear default queue stats
<1/QSC=5 will clear stats of rule-5.
Command only.
Setting QSA=1 will clear all qos queue statistics. Also clears the
default queue stats.
0| 0| 0| 0| 0| 0| 0chr(13)
0| 0| 0| 0| 0| 0| 0chr(13)
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
QST! QST? QST=sssssssss...
String displaying qos
stats of all active queues.
\r – CR – 0x0D
\n – Newline – 0x0A
QSC= None QSC=xx
QSC!
(see description of
argument)
QSA= None QSA=x
QSA!
(see description of
argument)
MN/CDM570L.AA4
