Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Number of QSN QSN=2 bytes
QOS Rule numerical
entries
Delete a QOS QSD= QSD =2bytes,
Rule entry numerical
QoS Typical QTL= 1-Byte value
System 0 – 5 Seconds.
Latency
QoS QML= 1-Byte value
Maximum 0 – 5000 milli
System Seconds.
Latency
Page 14 of 54
Description of Arguments
to Query
Query Only.
Returns the number of active qos rules. Doesnot count default rule.
Note: This command should be issued whenever a new rule is
added/deleted.
Command Only.
Deletes the QoS rule entry at the specified index number
Example: QSD=3 (deletes the 3
Command or Query
Sets/Gets the QoS typical system latency
At low datarates of upto 1Mbps this value can range from 0 – 5
Seconds..
At datarates above 1Mbps, the value range from 0 – 2 Seconds.
Query
Gets the QoS typical system latency
Value range from 0 – 5000 milli Seconds.
rd
qos rule)
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
QSN = QSN? QSN = xxx
QSN? (see description of
arguments)
QSD = N/A QSD = xx
QSD! (see description of
arguments)
QTL = QTL? QTL=x
QTL! X – A value of 0-5
Seconds.
QML = QML? QML=x
QML! X – A value of 0-5000
milli Seconds.
