CDM-570/570L Satellite Modem with Optional IP Module
Appendix F
F.3.3.11 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER)
FREQUENCY
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER)
FREQUENCY
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER)
FREQUENCY
ODU Tx Frequency:
5912.5 MHz (
The user is prompted to edit the transmit frequency. This is accomplished by selecting
the digit to be edited, using the
using the
F.3.3.12 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER)
ATTEN (Attenuation)
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER)
ATTEN (Attenuation)
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER) ATTEN
(Attenuation)
ODU Tx Attenuation:
15.00 dB
The user is prompted to edit the transmit attentuation. This is accomplished by selecting
the digit to be edited, using the
using the
F.3.3.13 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER)
AMPLIFIER
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER)
AMPLIFIER
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER)
AMPLIFIER
ODU Tx Amp State:
On
The user is prompted to select either On or Off, using the
ENT.
◄ ►,▲ ▼,
▲ ▼ arrow keys. The user may then press ENT.
◄ ►,▲ ▼,
(
◄ ►
▲ ▼ arrow keys. The user then presses ENT.
◄ ►
Off (
ENT)
◄ ► arrow keys. The value of the digit is then changed
ENT)
arrow keys. The value of the digit is then changed
,ENT)
F–6
Revision 4
MN/CDM570L.IOM
◄ ► arrow keys, then to press
