CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
6.7.10

(CONFIG, TX) INVERSION FUNCTIONS

Tx Inversion functions:
Spectrum
Select Spectrum or Data, using the
Data (◄ ►,ENT)
(CONFIG, TX, INV) SPECTRUM
If Spectrum is selected, the following sub-menu will be displayed:
Tx Spectrum:
(◄ ►,ENTER)
Inverted
Select Normal or Inverted, using the ◄ ► arrow keys, then press ENTER.
(CONFIG, TX, INV) DATA
If Data is selected, the following sub-menu will be displayed:
Tx Data Sense:
(◄ ►,ENTER)
Inverted
Select Normal or Inverted, using the ◄ ► arrow keys, then press ENTER.
◄ ► arrow keys, then press ENTER.
Normal
Normal
6–19
Revision 4
MN/CDM570L.IOM
