CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
17.2.8.7 Block Up Converter (BUC) Configuration
The Block Up Converter (BUC) Configuration page is activated from the Configuration
page.
The Block Up Converter (BUC) Configuration page contains the following options/fields:
Menu Options/Fields
BUC Address
BUC RF Output
BUC DC Power
BUC 10 MHz Reference
BUC Current Alarm Upper Limit (mA)
BUC Current Alarm Lower Limit (mA)
BUC LO Frequency (MHz)
Save Paramexters
Exit
Entry Description
A 1 to 15
Enabled/Disabled
R
W Enabled/Disabled
P Enabled/Disabled
H 500 to 4000
C 0 to 3000
3000 to 65000, 0 to disable
F
S This option allows a user to save the current
configuration to permanent storage. This
configuration will be restored on each
successive power cycle.
X This option allows a user to exit the current
menu and return to its parent menu.
17–55
Revision 4
MN/CDM570L.IOM
