IP Module Working Modes

Two Working Modes of the IP Module are available: easyConnect™ and Router Mode.
There are also three HDLC Addressing Modes: Point-to-Point, Small Network, and Large
Network. Separate HDLC Modes allows the user to minimize the HDLC overhead
transmitted over the satellite based upon the size of their network. In Router/Point-to-
Point Mode, no HDLC address is transmitted; Router/Small Network transmits 1 byte
and Router/Large Network transmits 2 bytes as part of HDLC header for each packet.
Non-IP traffic is not supported in Router Mode.
This section describes the functionality of these modes in order to optimize the
Comtech EF Data IP modems in the network, based upon Network Topology and
Ethernet Traffic requirements.
The Working Mode and HDLC Address Mode of the Comtech EF Data IP modems
must be identical to pass traffic between modems.
Changing the Working Mode or HDLC address Mode of the IP modem requires the IP
IMPORTANT
Module to be rebooted. Before the user can select a different mode, the IP Module
will notify the user that changing the mode will require a reboot.
Working Mode
HDLC Address Mode
easyConnect™ Mode
Point-to-Point
Router Mode
Point-to-Point
Router Mode
Small Network
Router Mode
Large Network
Network Topology
Point-to-Point only
Both sites on same LAN subnet
Point-to-Point only
Both sites on different LAN subnet
Point-to-Point or Point-to-Multipoint
(up to 254 sites)
All sites on different LAN subnet
Point-to-Point or Point-to-Multipoint
(up to 32766 sites)
All sites on different LAN subnet
16–2
Revision 4
MN/CDM570L.IOM
Ethernet Traffic
IP v4 and/or non-IP
IP v4 only
IP v4 only
IP v4 only
