CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
(CONFIG, ODU, BUC) M&C-FSK
BUC M&C(FSK): FSK-Comms
Address Tx-On/Off
If M&C-FSK is selected, the following sub-menu is displayed:
Select Comms, Address, or Tx-On/Off, using the ◄ ► arrow keys, then press
ENTER.
If an FSK-capable BUC is employed, this menu turns
FSK-Comms the FSK between the modem and BUC either ON or
OFF.
(Address) This menu permits the user to enter the
Address
logical address of the BUC, from 1 to 15.
(CONFIG, ODU, BUC, M&C-FSK) FSK-Comms
If FSK-Comms is selected, the following sub-menu is displayed:
BUC M&C FSK Comms:
On Off
Select On or Off , using the ◄ ► arrow keys, then press ENTER.
(CONFIG, ODU, BUC, M&C-FSK) Address
If Addr is selected, the following sub-menu is displayed:
BUC FSK Address: 01
Edit the value of the address using the ▲ ▼ arrow keys, then press ENTER. The
valid range is from 01 to 15.
(◄ ►)
(◄ ►,ENTER)
(▲ ▼,ENTER)
6–36
Revision 4
MN/CDM570L.IOM
