CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
6.18.4

(UTIL) ID (Circuit ID)

Edit Circuit ID:(◄ ►,▲ ▼)
24 CHARACTER TST MESSAGE
Edit the Circuit ID string, using the
available (24 characters). The cursor selects the position on the bottom line (
the character is then edited (
Space ( ) * + - , . / 0-9 and A-Z.
When the user has composed the string, press ENTER.
6.18.5

(UTIL) 1:1 (Manual 1:1 switchover)

Press ENT to force modem
to Standby (1:1 ONLY)
If the unit is part of a 1:1 redundant pair of modems, and this unit, is currently on-line,
pressing ENTER will cause the unit to switch to standby. Pressing CLEAR will exit the
menu without causing the switchover.
6.18.6

(UTIL) VFD (VFD Display brightness)

Edit Display Brightness:
100%
Edit the display brightness, using the
ENTER.
◄ ►
and
▲ ▼
). The following characters are available:
▲ ▼
(▲ ▼,ENTER)
arrow keys. The user should then press
▲ ▼
6–61
MN/CDM570L.IOM
arrow keys. Only the bottom line is
Revision 4
◄ ►
) and
