CDM-570/570L Satellite Modem with Optional IP Module
Appendix F
F.3.3.18 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) FREQUENCY
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) FREQUENCY
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER)
FREQUENCY
ODU Rx Frequency:
3912.5 MHz (
The user is prompted to edit the receive frequency. This is accomplished by selecting the
digit to be edited, using the
using the
F.3.3.19 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) ATTEN
(Attenuation)
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) ATTEN
(Attenuation)
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) ATTEN
(Attenuation)
ODU Rx Attenuation:
15.00 dB
The user is prompted to edit the receive attentuation. This is accomplished by selecting
the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed
using the ▲ ▼ arrow keys. The user then presses ENT.
F.3.3.20 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER)
(ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER)
(ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) MUTE
ODU Rx Mute State:
Muted
The user is prompted to select either Muted or Unmuted, using the
then to press ENT.
◄ ►,▲ ▼,
◄ ►
▲ ▼
arrow keys. The user then presses ENT.
◄ ►,▲ ▼,
(
◄ ►,
Unmuted ( ENT)
ENT)
arrow keys. The value of the digit is then changed
ENT)
F–8
Revision 4
MN/CDM570L.IOM
MUTE
MUTE
◄ ► arrow keys,
