CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
Menu Options/Fields
IP Statistics
QoS Statistics
Ethernet Statistics
WAN Statistics
Compression Statistics
Clear all stats
Save Parameters
Exit
IMPORTANT
Entry
R
Q
E
W
H
C
S
X
All updates for Statistics information will occur once every 6 seconds.
Description
Displays Statistics for IP Routing and allows counters
to be reset.
Displays Statistics for QoS and allows counters to be
reset.
Displays Statistics for the Ethernet Port and allows
counters to be reset.
Displays Statistics for the WAN (HDLC) Port and
allows counters to be reset.
Displays Statistics for Header & Payload Compression
and allows counters to be reset.
Globally resets all statistics counters.
This option allows a user to save the current
configuration to permanent storage. This configuration
will be restored on each successive power cycle.
This option allows a user to exit the current menu and
return to its parent menu.
