Administration Page - Comtech EF Data CDM-570L Installation And Operation Manual

CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
17.2.1

Administration Page

The Administration page is activated from the Main Menu page.
Access to the Administration page is restricted to the Admin user when connecting
via the Telnet, SNMP, or HTTP interface. The Administration page is available when
connected via the Terminal Emulator (serial) connection because there is no log in.
IMPORTANT
The Administration page contains the following options/fields.
Menu Options/Fields
Name/Password
Configuration
Access Lists
Feature Configuration
Entry
Activates Name/Password Configuration page. Allows
P
the user to define the user name and passwords that
are required in order to access the management
interfaces.
A Activates Access Lists page. Allows the user to restrict
access to the management interfaces based upon the
requester's IP address.
F Activates Feature Configuration page.
17–5
MN/CDM570L.IOM
Description
Revision 4
