CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
CHANGING THE STATE OF DEMO MODE WILL CAUSE THE MODEM FIRMWARE TO
REBOOT. ALSO, IF DEMO MODE IS ENABLED AND THE TIMER EXPIRES THE
MODEM FIRMWARE WILL REBOOT.
IMPORTANT
If the user selects Demo Mode, then the following menu is displayed:
FAST Demo Mode: Off
604800 seconds remain
Use the ◄ ► arrow keys to move the cursor to select Off or On. When
On, the second line will display the number of seconds remaining
available for the free Demo Mode. When enabled, Demo Mode allows
access to ALL CDM-570/570L FAST options for 604800 seconds (7 full
days). Demo Mode may be turned on and off an unlimited number of
time until the 604800 seconds have expired. The seconds count only
decrements when the mode is On. When the Demo period expires the
following menu is displayed:
FAST Demo Mode: Off
Demo Period Expired
If the user selects View, then the following menu is displayed:
View Options: 03
150W BPSU Not Installed
Use the arrow keys to scroll through each Option Number in turn. As the
▲ ▼
cursor highlights each option, the description of the option will be displayed on
the bottom line, along with the information "Installed or Not Installed". The
options are shown in the following table:
On
On
(▲ ▼)
6–64
Revision 4
MN/CDM570L.IOM
