CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
6.18.7

(UTIL) FIRMWARE

This series of sub-menus permits the user to view information about the CDM-570/570L
internal firmware. The modem can store two complete firmware images, and the user can
select which image will be loaded the next time the unit re-boots.
THESE MENUS ARE FOR DIAGNOSTIC PURPOSES. ONLY CHANGE AN IMAGE IF
INSTRUCTED TO DO SO BY COMTECH EF DATA CUSTOMER SUPPORT
TECHNICIANS.
IMPORTANT
Firmware Images:
Info
Select either Info or Select, using the
(◄ ►,ENTER)
Select
If Info is selected, the following sub-menu is displayed:
Firmware Info: Bootrom
Image#1 Image #2
Use the ◄ ► arrow keys and ENTER key to select and view information about
the Bootrom, the 2 images, or the IP module (if installed).
Each image is further broken down as follows:
Image#x: Bulk
App Turbo-FPGA
Use the ◄ ► arrow keys and ENTER key to select which element is then
displayed. A screen similar to the one shown below will be displayed:
Bulk#x:
FWxxxx
If the user selects Select, the following sub-menu is displayed:
Current Active Image: #1
Next Reboot Image: #1 #2
The top line shows the current active image. On the bottom line the user may
◄ ►
select, using the
the next time the unit is re-booted.
◄ ►
arrow keys. Press ENTER.
MPP50
Main-FPGA
RS-FPGA
01/21/04
1.1.1
arrow keys and ENTER key, the image that will be active
6–62
Revision 4
MN/CDM570L.IOM
