CDM-570/570L Satellite Modem with Optional IP Module
IP Module - CLI and Telnet Operation
17.2.9

Operations and Maintenance Page

The Operations and Maintenance page is activated from the Main Menu page.
The Operations and Maintenance page contains the following options/fields:
Menu Options/Fields
Unit Uptime
Unit Information
IP Module Boot From
Base Modem Boot From
Entry
Read Time in days, hours, mins and secs since the last time
Only the IP module was rebooted.
I Displays unit current operational Software information.
B Determines which version of the
package (includes Application, FPGA, and FFPGA) will
be loaded upon boot-up. The possible options are:
0. Latest - boot the newest software package based
upon date.
1. Image1 - boot the software package loaded into the
first slot in permanent storage.
2. Image2 - boot the software package loaded into the
second slot in permanent storage.
Determines which version of the Base modem firmware
A
will be loaded upon boot-up. The possible options are:
0. Latest - boot the newest software package based
upon date.
1. Image1 - boot the software package loaded into the
first slot in permanent storage.
2. Image2 - boot the software package loaded into the
second slot in permanent storage.
17–57
MN/CDM570L.IOM
Description
IP M
odule software
Revision 4
