CDM-570/570L Satellite Modem with Optional IP Module
Installation
BRACKET
BOLTS
Figure 2-1. Installation of the Optional Mounting Bracket
#10 Shoulder Screw
#10 Flat W asher
Support
Bracket
Bracket
#10 Flat W asher
#10 Split W asher
#10 Hex Nut
Equipment
Rack
Mounting
Rail
Back of Modem
2–3
Revision 4
MN/CDM570L.IOM
